Certi-Lite
- Single-ended ANSI/TIA 1152-A compliant RF testing involving the measurement of complex cable parameters such as Return Loss, NEXT, Insertion Loss, ACRF, length, delay, shield discontinuity, and graphical TDR analysis of faults.
Fiber Optic Loopback and Voltage for Hybrid Powered Fiber
- OTDR troubleshooting with Singlemode and Multimode test adapters.
- Loopback testing with Singlemode and Multimode test adapters ensures cable quality and includes reports of all supported network speeds based on cable performance.
- Integrated VFL identifies cable breaks.
- Fiber scope identifies debris or scratches that could affect cable quality.
- Measures DC Resistance in Hybrid powered fiber.
PoE Load Testing
- All PoE standards, which include 802.3 af/at/bt and UPoE are supported for reporting of PSE configuration and full load testing with reporting of Current/Wattage/Voltage. In addition, it also allows for sustained loading of the PoE source over longer periods to identify hard to find intermittent power drops, through external loads.
Multi-gig Link Speed Testing
- Signal-to-Noise Ratio (SNR) testing of link speed, while under both traffic and PoE load up to 10GigE to provide assurance the cabling link will support the desired network rate up to 10GigE.
Network Connectivity Testing
- Network discovery with drill down into seen devices.
- Switch detail include slot/port/VLAN.
- Troubleshooting Toolkit includes Traceroute, Ping, Traffic Generator, and TCP Connect.
- Network Autotest feature including savable report.
Wi-Fi Testing
- Auto-discover all 2.4GHz and 5GHz Wi-Fi SSIDs and their associated RSSI values (received power level).
- Roaming signal strength tool useful for uncovering Wi-Fi “dead zones”.
- Troubleshooting Toolkit includes Traceroute, Ping, Traffic Generator, and TCP Connect.
- An optional Wi-Fi USB Adapter is required and must be purchased separately.
